FEATURES:
- Passive Infrared Technology (PIR)
- Simple, fast installation
- Energy efficient –
- Multi-level, 360° Fresnel lens for superior occupancy detection
- Manual adjustable ambient light level prevents load from turning ON automatically during periods of ample natural light
- Zero crossing function
- Conforms to California Title 24 Requirements
- Three years warranty
SPECIFICATION
- Input Voltage: 120/277VAC
- Operating Temperature: 32°F to 131°F (0°C to 55°C)
- Adjustable Light Level: 10FC-150FC
- Adjustable Time Delay: 15sec.-30min
- Sensitivity Adjustment: 50% or 100% (DIP switch 1)
- Load Rating: Incandescent: 800w @ 120BAC, 60Hz Fluorescent: 800VA @ 120VAC/ 1600VA @ 277VAC, 60Hz Resistive: 800W @ 120VAC, 60HZ Motor: 1/4HP, 120VAC, 60Hz LED: 100W
TYPICAL APPLICATIONS:
- Storage Areas
- Small Bathrooms
- Copy Rooms
- Computer Rooms
- Conference Rooms
- Classrooms
- Warehouses
